| Parameter |
|
| Where not defined here, all specifications are equal to the standard PPA5500 |
|
| Weight |
5.4kg (1 Phase), 6kg (3 Phase) |
W, VA, VAr, V & A – rms, fundamental,
AC, DC, Peak, Surge, +ve Pk, -ve Pk |
|
| Voltage Input Accuracy (16 to 450Hz) %Rdg + Rng |
|
| Standard Accessories |
|
| Safety Isolation |
1000Vrms or DC (CATII), 600Vrms or DC (CATIII) |
| Power Supply |
90 ~ 265Vrms, 50 ~ 60Hz, 40VA Max |
| Power Accuracy (Watts) Total % error |
|
| Phase Accuracy (16 to 450Hz) |
|
| PF 1 to 0.5 |
0.0015 |
| PF 1 to 0.5 |
0.0017 |
| PF 1 to 0.5 |
0.0018 |
| PF 1 to 0.5 |
0.0019 |
| PF 0.5 to 0.05 |
0.0023 |
| PF 0.5 to 0.05 |
0.0026 |
| PF 0.5 to 0.05 |
0.0028 |
| PF 0.5 to 0.05 |
0.0031 |
| PF 0.05 to 0.02 |
0.0048 |
| PF 0.05 to 0.02 |
0.0052 |
| PF 0.05 to 0.02 |
0.0056 |
| PF 0.05 to 0.02 |
0.0064 |
| PF 0.02 to 0.01 |
0.0055 |
| PF 0.02 to 0.01 |
0.0089 |
| PF 0.02 to 0.01 |
0.0106 |
| PF 0.02 to 0.01 |
0.0124 |
| Other documents |
Calibration certificate, Quick start guide |
| Operating Range |
DC, 10mHz-2MHz – 1000Vrms (3000Vpk) – 30Arms (300Apk) |
| Operating Conditions |
5 deg to 40 deg ambient temperature (or air intake temperature when rack mounted), 20-90% Non-condensing relative humidity. |
| Number of Phases |
44621 |
| Mechanical and Environmental |
|
| Leads |
Power, RS232, USB |
| Instruction manual |
User manual, Communications manual |
| General |
|
| Display |
320×240 dot full colour TFT, White LED backlit |
| Dimensions |
130H x 400W x 315D mm excluding feet |
| Current Input Accuracy (16 to 450Hz) %Rdg + %Rng |
|
| Corrected Power, normalised mean, rectified mean, form factor, crest factor, Delta-Star, Star-Delta, Cycle-by-Cycle, Harmonic and Flicker analysis |
|
| Connection Clips |
4mm terminated alligator clips ? 1x red, 1x yellow and 2x black per phase (1x red, 1x black per phase with HC version) |
| Connection Cables |
36A 1.5m long 4mm stackable terminals. 1x red, 1x yellow, 2x black per phase (1x red, 1x black per phase with HC version) |
| Communication Ports |
RS232, GPIB, LAN port, Rear USB Communication Port, Analogue output, Speed input, Torque input, Sync, Extension, Front USB screenshort/data storage port |
| Calibration Interval |
24 Months |
| 66-180Hz |
|
| 66-180Hz |
0.006deg |
| 45-65Hz |
|
| 45-65Hz |
0.003deg |
20%-120% of range in 100Vpk and 300Vpk ranges
(14Vrms to 250Vrms) |
0.01% + 0.038% |
20%-100% of range in 1 Apk, 3Apk and 10Apk ranges
(0.14Arms to 7Arms) |
0.01% + 0.038% |
| 181-450Hz |
|
| 181-450Hz |
0.007deg |
| 16-44Hz |
|
| 16-44Hz |
0.005deg |
|
