Precision Power Analyzer | PPA5500
Call for pricePrecision Power Analyzer PPA5500 Overview
The PPA5500 Power Analyzer introduced leading power measurement performance in a compact, cost-effective instrument that quickly developed a reputation for exceptional accuracy and stability in the most demanding of power applications. The series extends the power analysis range further for those who need the ultimate power analysis product, this is the top-of-the-range model offered by N4L and rightly deserves its place. While maintaining the wide frequency range and exceptional noise rejection, the PPA5500 series adds increased voltage and current measurement ranges, greater processing power, increased memory, real-time clock, high contrast color display, 1GB non-volatile internal memory, and external USB memory port. A 2MS/s sample rate, alongside “True Real-Time” no gap analysis is a formidable combination for the analysis of power, this – along with innovative analog front end design which includes our proprietary “Planar shunt technology “, the PPA5500 provides truly exceptional measurement stability and accuracy. The phase angle accuracy of the PPA5500 is 0.005 degrees, this is perfect for transformer loss analysis testing at very low power factors. Have a look at the Power Analyzer Tutorial Series which demonstrated the speed and versatility of the PPA5500.
Precision Power Analyzer PPA5500 Features and Benefits
- 0.01% Basic accuracy
- Frequency range DC and 10mHz to 2MHz
- High precision internal shunts Superior accuracy to any external shunt
- 5 millidegree phase accuracy necessary for low power factor applications
- Up to 50 Arms (1000 Apk) & 1000 Vrms (3000 Vpk) direct input
- Low current (10Arms), Standard (30Arms), and High current (50Arms) options
- High-speed sampling on all channels
- True real-time analysis with no measurement gap
- 1, 2, or 3 phase versions master-slave mode for 4, 5, or 6 phase
- Real-time Digital, Tabular, Graphic, and Oscilloscope displays
- Simple BNC connection of N4L shunts for high current applications
- RS232, IEEE 488, USB, LAN, Torque, Speed and Extension ports
