Monitoring System

The Rotronic Monitoring System is a modular system of hardware elements and web-based software. It provides maximum flexibility in installation and ensures readily available data. The data loggers record measurements from Rotronic and third-party sensors and transmit them to the secure database. It stores information and makes it available to users, regardless of whether they access the database via a PC, Mac, tablet or smartphone.

The continuous monitoring system RMS Rotronic meets the requirements of "IoT" and "M2M".

Internet of Things (IoT) and machine to machine (M2M) communication are main factors in the design principles of Industry 4.0 that was introduced in 2011 at the Hannover Fair in Germany. The design principle is interoperability, where sensors, devices, machines and people can connect and communicate.

An IoT ecosystem is built up with sensors, that transmit data via a gateway to the Internet. The data is then stored in a certified datacentre. With software, the data is then analysed and again via the Internet, the analysed data can be sent out to remote devices.

This leads to another design principle which is decentralised decision making. From the remote devices and analytics, decisions can be made and commands can be sent, once again via Internet to the IoT devices. The remote devices allow for a third design principle: technical assistance. Services can be carried out directly from the results of the measurement devices.

THE MAIN SOFTWARE FEATURES:

  • Alarm overview - see directly how many alarms are active and where it is coming from
  • Receive alerts via interactive phone, texts and E-Mails
  • Audit trail to see exactly what happened and when
  • Monitor multiple locations - one system for all your monitoring locations
  • Input floor plans - get a real overview of the setup
  • Scalable - prefect for single points in small installations to thousands of points in worldwide installations
  • Automatic report generation
  • Integration of Rotronic and any third party hardware - analogue and digital
  • Create custom dashboards per user
  • FDA 21 CFR Part 11 & EU Annex 11 complaint
  • GAMP©5 conform for GxP applications
  • Automatic validation scripts - for fast and effective OQ validation
  • Continuously developing based around customer feedback

ADDITIONAL FEATURES:

  • Add an IP camera and add a snap shot to your alarm report
  • Calibrate all of your measuring points, possibility to adjust all of the Rotronic devices
  • Archive all measuring points that are no longer needed, keeping access to the data for as long as necessary
  • Save all your documents in the system: user manuals, data sheets, calibration certificates, SOP’s...

REGISTER NOW FOR A FREE DEMO ACCOUNT!



Rotronic Remote Monitoring System

  •  2

    Wireless Mini Data Logger – RMS-MLOG

     R3,273.00 – R4,552.00

    Wifi Mini Data Logger

    The mini data logger is a low-cost wireless data logger use wit the ROTRONIC monitoring system. Its small housing and wireless interface make it a really flexible.

    Wireless Data logger variants:

    • Temperature & Humidity
    • Temperature sensor (NTC)
    • External temperature sensor (NTC)
    • Light
    • Voltage measurement,
    • Current measurement 0-20mA
    • Digital switch contact

    With this versatility, it can monitor refrigerators and incubators, as well as door contacts and OEM analog devices.

    Data Logger Features
    • Conforms to FDA 21 CFR Part 11 / GAMP5
    • Stores 10,000 measured values
    • Syncs with remote database when connected
    • The internal battery is a Fail-safe
    • Battery lifetime 3 years
    • Depending on the version, it measures temperature, current, voltage, or light, or monitors a digital switch input
    • Compatable to FDA 21 CFR Part 11 / GAMP5

    Requires a RMS Gateway connected to Internet, together with software RMS server software or RMS Cloud

    Select options

  • Remote Monitoring System Gateway, Interface between 868 MHz and LAN

    Gateway for RMS converts Wifi 868MHz to LAN, RMS-GW-868

     Call for price

    Gateway between Wireless Loggers and Software via LAN

    The Gateway is the interface between the wireless data logger and remote software via LAN Ethernet connection. The Gateway can manage up to 60 data loggers simultaneously, collecting all wireless-logger measurement data, and passing them on to the server software. When several Gateways are used in the same network, they are configured redundantly. If one Gateway should fail, the measurement values are automatically sent to the server software via another Gateway.

    Gateway Features
    • Complies to FDA 21 CFR Part 11 / GAMP5
    • Up to 60 wireless data loggers simultaneously
    • 5 wireless channels for parallel and redundant operation
    • Compatible with RMS server software and RMS Cloud

    Read more

  • Standard Temperature & Humidity probe for RMS, Data logger, black

     Call for price

    Temperature and Humidity Probe for Remote Monitoring

    The HCD-S digital probe is characterised by its high performance with a new AirChip4000 chip, which together with the new HYGROMER® HT-1 sensor forms a powerful combination. With measurement results within 50 ms (electronics) it consumes very little energy without loosing accuracy.

    Humidity and Temperature probe Features
    • Compatible with RMS data loggers (RMS-LOG) and RMS software
    • Measures relative humidity and temperature, calculates the dew point
    • With new HYGROMER® HT-1 sensor
    • Outstanding accuracy and repeatability
    • Accuracy ±0.8 %RH
    • Excellent long-term stability <1 %RH / year
    • Developed for very low power applications
    • Digital calibration and adjustment
    • Software Conforms to FDA 21 CFR Part 11 / GAMP 5

    Read more

  • RMS Data logger, external probe, LAN or 868

     R6,546.00 – R7,290.00

    Temperature and Humidity Data Logging Transmitter via Monitoring system on the Cloud or direct to your network server.

    The data logger captures data from a probe and transmits it to a database in the ROTRONIC Monitoring System. It guarantees absolute data protection, even if power supply and communications should temporarily break down. As it stores 44,000 pairs of measured values from the exchangeable HygroClip probe, and transmits them to the RMS database via LAN.

    Humidity Data Logger Features

    • LAN Interface plug directly into a router with internet connection.
    • FDA 21 CFR Part 11 / GAMP5 compliant
    • Measures and Stores 44,000 pairs values
    • Fail-safe, thanks to internal battery
    • 3 years battery lifetime
    • Compatible with RMS Gateway, RMS server software and RMS Cloud

    Requires: interchangeable HygroClip probe and a cloud software account with Rotronic or the purchased software on you own server.

    Select options
