Digital Temperature Probe | RMS-TCD-S-001

Digital Temperature Probe | RMS-TCD-S-001

R9,961.00 ex vat

Digital Temperature Probe – Overview

The RMS-TCD-S-001 digital probe measures temperature with outstanding repeatability, accuracy and long-term stability.  They are designed for all temperature monitoring applications where accuracy and interchangeability are crucial. The temperature probe is attached to a 2m cable to ensure flexibility and ease of use during calibration. Monitors conform to the GxP and FDA 21 CFR Part 11. Widely used in the Pharmaceutical, Food and Beverage and Museum industries.

Digital Temperature Probe – Features

  • Outstanding accuracy
  • Outstanding repeatability
  • Long-term stability
  • Advanced probe housing and construction
  • Compatible with RMS data loggers and RMS software
  • Low power consumption
  • Digital communication
  • Hot swap possibility, ensuring little to no downtime
  • Automatic serial number replacement documented within the RMS audit trail

Description

Digital Temperature Probe | RMS-TCD-S-001

Temperature sensor 4 wire PT100 1/3 DIN (DIN EN 60751
Long-term stability ±0.5 °C/year
Measuring range -200…200°C* (*see data sheet / siehe Datenblatt / voir fiche technique / vedere scheda tecnica)
Relative humidity range 0…100 %rh
Digital output signal (standard) UART
Storage Conditions -40…85 °C
IP protection rating Housing: IP65 Sensor : IP68
Connector Standard Rotronic 7-pin connector
Length 110 mm
Communication interfaces MODBUS RTU
Probe material Stainless steel – austenitic – 1.4571 (316Ti) bar
Probe cable material Perfluoroalkoxy alkanes (PFA)
Enclosure material Polycarbonate
Probe lengths 50 mm
Housing Yes
Current consumption -3.8 mA
Power supply 3.3…5 VDC
Adjustment Option 1: 2 point user adjustment possible Option 2: A, B and C coefficients
Evaluation software / Compatibility RMS Config; Rotronic Monitoring System
T63 90 s
Battery lifetime RMS-LOG-868/915/L: @60 s 240 d RMS-LOG-L-D: @60s 18 d
Cable lengths 2 metres
Accuracy ±0.25 °C at -50…85 °C
Diameter 15 mm
Cable diameter 2.2 mm
Probe diameter 3 mm

Calibration certificates are issued during the production process. New calibration certificates are available upon request at an additional cost.

Digital Temperature Probe | RMS-TCD-S-001

Brand

Rotronic
