Water Treatment

  • Thread Thermal Mass Flow Meter RWMF Thread

    Thread Thermal Mass Flow Meter | RWMF Thread

    Thread Thermal Mass Flow Meter - Overview

    The Thread Thermal Mass Flow Meter is popular in industrial applications due to its design. It features no moving parts, a nearly unobstructed straight-through flow path, requires no temperature or pressure corrections and retains accuracy over a wide range of flow rates. Straight pipe runs can be reduced by using dual-plate flow conditioning elements. Simple installation with minimal pipe intrusions. It is mainly used to measure dry gas, such as Air, Natural gas, LPG gas, Biogas, etc. Not suitable for Vapour, Humid gas and Ethyne.

    Thread Thermal Mass Flow Meter  - Features

    • Wide range ratio 1000:1
    • Large diameter, low flow rate
    • Direct mass flow measurement without temperature & pressure compensation
    • Sensitive low flow rate measurement
    • Easy to install and use
    • Suitable for single or mixed gas flow measurement
    • Could measure gas with flow velocity from 100Nm/s to 0.1Nm/s, which can be used for gas leak detection
    • The sensor has no moving parts or pressure-sensing parts
    • Not affected by vibration on the measurement accuracy
    • Good seismic performance and high measurement reliability
    • No pressure loss or negligible pressure loss
    • Supports multiple communication methods: RS485, MODBUS protocol, etc.

    Read more

  • Clamp Thermal Mass Flow Meter RWMF

    Clamp Thermal Mass Flow Meter | RWMF Clamp

    Clamp Thermal Mass Flow Meter - Overview

    This one-of-a-kind mass flow meter is popular in industrial applications because of its design and build. It has no moving parts, a nearly unobstructed flow path and requires no temperature or pressure corrections. It is not affected by vibration on the measurement accuracy. It has good seismic performance and high measurement reliability. It also retains accuracy over a wide range of flow rates. Straight pipe runs can be reduced by using dual-plate flow conditioning elements. Installation and use are easy with minimal pipe intrusions. Mass flow meter sizes range from DN15~DN100mm. Its sensitivity is suitable for low flow rate measurement.  Applications include single or fixed gas flow measurements. It measures gas with flow velocity from 100Nm/s to 0.1Nm/s. The flow meter can also be used for gas leak detection.  It supports multiple communication methods, such as RS485 and MODBUS protocol for factory automation and integration.

    Clamp Thermal Mass Flow Meter  - Features

    • Measuring Medium: Various of Gas (Except acetylene)
    • Pipe Size: DN15-DN2000mm
    • Velocity: 0.1-100Nm/s
    • Accuracy: +/-1~2.5%
    • Working Temperature: Sensor:-40~+220 degC
    • Transmitter:-20~+45 degC

    Read more

  • Standard Vortex Flow Meter QT LUGB

    Standard Vortex Flow Meter | QT LUGB

    Standard Vortex Flow Meter - Overview

    The Standard Vortex Flow Meter is robust and measures the flow volume of non-conductive liquids, gases, and saturated and superheated steam. The vortex flow meter can add temperature and pressure compensation. It has an embedded sensor, with 4 piezo-electric crystals encapsulated inside the sensor, which is patented. There are no moving parts, and no abrasion, and the non-wearing parts inside the vortex flow meter sensor are in a fully welded SS304 body (SS316 selectable). It eliminates drift & vibration influence well compared to other meters. It can also work as a BTU meter to measure steam or hot water energy. It has a wide range of applications.

    Standard Vortex Flow Meter - Features

    • Suitable Mediums: Liquid, Gas, Steam
    • Medium Temp: -40℃~+200℃; -40℃~+250℃; 40℃~+350℃
    • Accuracy: 1.0% (Flange), 1.5% (Insertion)
    • Material: SS304 (Standard), SS316 (Optional)
    • Nominal Pressure: 1.6MPa;2.5MPa;4.0MPa (Other pressure can be customised)

    Read more
